ECORUN Stripe Chrome LED Downlight has a great collection of downlights and recessed lighting for sale, offering a sleek and modern lighting solution. Installed flush to the ceiling, polished led downlight recessed can brighten up your home’s interior, and help create a welcoming environment while offering a compact and elegant look to a room’s decor.
Stripe LED Downlight 40W is easily one of the most stylish and functional additions you can make to your home or commercial space.As suppliers of recessed lighting, we’re seeing it used more and more in both new construction and retrofit applications. Quality recessed lights not only provide a clean and polished look, they’re energy efficient and last longer than ordinary bulbs.
If you’re looking for the most cost-effective option, our Lite collection provides the benefits of an impressive lamp lifespan of 50,000 hours and a five-year extended warranty.
- CREE COB light source,Ra80/Ra90.
- LIFUD/XZ-POWER/AD/LINKUAN drivers.
- New private module housing design,better heat dissipation with thicken Aluminum.
- White housing,high brightness polished reflector,PMMA lens.
- Paint baking surface,never fade,and anti-scratch.
- Triac,0/1-10V,DALI dimmable options are all available.
- Ease of installation and maintenance.
- Can work with motion sensors.
- Rated Life: 50,000 hrs.
- Limited Warranty: 3 years (5yrs and 7yrs optional).
Professional-grade LED Downlights
New universal driver supports TRIAC,ELV & 0-10V dimming.High end.Superior performance.
True colors.
ECORUN LED downlights have Absolute White optics, which are rated at 3 step MacAdam Ellipses, making fixture-to-fixture color output highly consistent. In addition, they are black body accurate, making color shift minimal.
Smooth and pleasing light.
The microprismatic diffusion lens optimizes lumen output and delivers smooth, uniform illumination that enhances any space.
Easy installation.
Butterfly brackets allow a variety of ways to secure for 1/4" to 1/2" bar stock, nailer bars (included with rough-in), conduit bar stock or c-channels (optional). EZ-Connector allows you to finish installation without any wiring. Ceiling clamps automatically open and clamp down on the ceiling for super easy installation.
IC rating
For ceilings with insulation, ECORUN comes with an optional insulation contact housing.
SPECIFICATION
| Model No | ERDL-40W-A35 |
|---|---|
| Dimension | D220*H115mm Cutout:D195mm |
| LED Light Source/QTY | CREE COB CXA1820 light source |
| Power | 40W |
| Color Temp | 2700K/3000K/4000K/5000K/6000K |
| Luminous (lm) | 3000-3300LM |
| Lighting Effect | >100-110LM/W |
| CRI | 80/90Ra |
| P.F. | >0.95 |
| Power Efficiency | >89％ |
| Input Voltage | AC85-265V, 50/60Hz |
| Beam angle | 50° |
| Work Temp | -20~60℃ |
| Working Humidity | 10％-90％ |
| IP Rate | IP20 |
| Main Material | New private module housing design,better heat dissipation with small height |
| Frame color | White housing,Alu Silver heat-sink,stripe high brightness reflector,PMMA LENS |
| Lifespan | More than 50,000hrs |
| Warranty | 3 or 5 Years |
| Certification | CE ROHS SAA FCC TUV ETL |
DIMENSION： MOUNTING：
DIMMING： CONTROL：
