ECORUN LED Anti-glare Downlight A05 Series – 30W
30 Watt dimmable LED Downlight, 100-110lm/W up to 130lm/W, UGR<19, with Selectable CCT
Application
Perfect for residential or commercial applications
Design Specifications
30 watt integral flicker CONTROLLED dimmable driver with easy installation
High efficiency LED optics, multi-faceted optical system
Selectable CCT 3000K / 4000K / 5700K, CRI>80, 60deg beam distribution, UGR<19
Trailing edge dimmable LED driver, double insulated, white surface mount options available, D160*H133mm, cutout:D140mm.
Polyamide trim and body form white or black
Performance
Dimmable – YES
Dimmer Type – Trailing edge, optional 1-10V, DALI / DSI,CCT Selectable
LED lights can produce glare and limit visibility in some cases. However, by selecting the appropriate LED light, this can be considerably decreased and enhanced. That is why we recommend Anti-glare led downlight for your projects.
Because the LED light source is positioned further back within the downlight,ECORUN LED Anti-glare Downlight prevent discomfort from direct eye contact. They’ve grown in popularity in recent years since they have a more modern appearance than traditional downlights. Living rooms, baths, and commercial enterprises such as restaurants, casinos, and celebrations are just a few examples where Anti-glare led downlight are widely in trend.
Both indoors and outdoors, the use of no-glare lighting is highly advised. Their utilisation creates a more holistically enabling atmosphere, boosts human productivity, and reduces the risk of accidents. When it comes to interior lighting, glare control is significantly easier than when it comes to landscape lighting. However, glare from overhead lights is a major source of worry. Glare should be minimised in the design phase for outdoor spaces in particular.
ECORUN Anti-Glare LED Downlight include 3" 4" 5" 6" 8" led downlight size,and beam angle 15deg 24deg 38deg 60deg.Dimmable is optional,and has a lumen output of 100-110lm/w,up to 130lm/W.
Professional-grade LED Downlights
New universal driver supports TRIAC,ELV & 0-10V dimming.High end.Superior performance.
True colors.
ECORUN LED downlights have Absolute White optics, which are rated at 3 step MacAdam Ellipses, making fixture-to-fixture color output highly consistent. In addition, they are black body accurate, making color shift minimal.
Smooth and pleasing light.
The microprismatic diffusion lens optimizes lumen output and delivers smooth, uniform illumination that enhances any space.
Easy installation.
Butterfly brackets allow a variety of ways to secure for 1/4" to 1/2" bar stock, nailer bars (included with rough-in), conduit bar stock or c-channels (optional). EZ-Connector allows you to finish installation without any wiring. Ceiling clamps automatically open and clamp down on the ceiling for super easy installation.
IC rating
For ceilings with insulation, ECORUN comes with an optional insulation contact housing.
SPECIFICATION
| Model No | ERDL-50W-A05 |
|---|---|
| Dimension | D185*H156mm Cutout:D160mm |
| LED Light Source/QTY | CREE CXA-2530 COB light source |
| Power | 50W |
| Color Temp | 2700K/3000K/4000K/5000K/6000K |
| Luminous (lm) | 5000-5500LM |
| Lighting Effect | >100-110LM/W |
| CRI | 80/90Ra |
| P.F. | >0.95 |
| Power Efficiency | >89％ |
| Input Voltage | AC85-265V, 50/60Hz |
| Beam angle | 50° |
| Work Temp | -20~60℃ |
| Working Humidity | 10％-90％ |
| IP Rate | IP20 |
| Main Material | Cold forging system Aluminum housing,clear glass cover |
| Frame color | White surface housing,black heat-sink,clear glass cover |
| Lifespan | More than 50,000hrs |
| Warranty | 3 or 5 Years |
| Certification | CE ROHS SAA FCC TUV ETL |
DIMENSION： MOUNTING：
DIMMING： CONTROL：
